Overview
The Jam Sound Turntable (model HX-TTP200BK-GB) is an all-in-one vinyl playback unit with built-in speakers, designed to be a user-friendly entry point into vinyl. It supports three standard record speeds and offers connections for external audio gear.
You can see one listing of the product here:
Jam Sound Turntable
Key Features & Specifications
| Feature | Detail |
|---|---|
| Drive Type | Belt drive with auto-stop mechanism |
| Playable Speeds | 33 ⅓, 45, and 78 RPM |
| Built-in Speakers | Dual stereo speakers, 52 mm drivers, 1.5 W output per speaker; frequency response approx. 150 Hz to 15 kHz |
| External Output / Input | RCA output (for connecting to external speakers) and Aux-in (for feeding other audio sources) |
| Dust Cover | Integrated protective cover to block dust when not in use |
| Motor | DC servo-controlled motor |
| Power & Operation | Operates on 220-240 V AC. Power button to switch on/off. |
| Included Accessories | Power cord; tone arm lock; 45 RPM adaptor; stylus cover / guard |
Usage & Operation Highlights
-
Getting started : Remove the tone arm lock, place your vinyl on the platter, select the proper speed, lift and move the tone arm over the record, then gently lower it.
-
External audio : Use RCA cables to connect it to more powerful speakers or audio systems if you want louder or higher fidelity sound.
-
Care tips : Always return the tone arm to its rest, secure the lock, replace the stylus cover, and close the dust cover when not in use.
